The pneumatic reciprocating pump DESOI AirPower S25-2C combines high capacity with compact design. Due to the directly mounted seals on the piston, retensioning is not necessary. The result is a very maintenance-friendly machine.
MATERIAL TO BE USED
- two-component injection resins
TECHNICAL DATA
| Working pressure - infinitely variable | 10 - 100 bar |
| Delivery rate | max. 7.6 l/min |
| Air consumption | 1 m³/min |
| Air pressure | max. 8 bar |
| Transmission ratio | 1:13 |
| Air consumption and delivery rate at 100 bar back pressure (injection pressure) | |
| Air consumption 75 l/min | Delivery rate 0,5 l/min |
| Air consumption 133 l/min | Delivery rate 1 l/min |
| Air consumption 283 l/min | Delivery rate 2 l/min |
| Air consumption 391 l/min | Delivery rate 3 l/min |
| Mixing ratio | 1:1 |
| Weight | 20.2 kg |
| L x W x H | 58 x 24 x 46 cm |
WHAT IS INCLUDED
carrying frame, 1.5 m suction system Ø 20 mm with suction basket Ø 40 mm: component A: transparent, component B: black, 2 x manometer 0 - 250 bar, material hose connection: component A: external thread M16x1.5, component B: external thread M14x1.5, return hoses Ø 8 mm: transparent, air connection: air plug NW 7.2, incl. instruction manual
Product for professional use only.
