The combination DESOI w.i.l.m.a. and DESOI AirPower M35-3C VA is ideal for injection work with acrylic gel. The piston pump achieves a delivery rate of max. 13 l/min at a mixing ratio of 1:1 and is equipped with a separate rinsing pump. The sealing sets inside are protected by an integrated spring pre-tensioned, manual re-tensioning is not necessary. DESOI w.i.l.m.a. monitors and documents the material consumption, the injection pressure and the mixing ratio.
MATERIAL TO BE USED
- Acrylate gel
TECHNICAL DATA
| Working pressure - infinitely variable | 5 - 120 bar |
| Delivery rate | |
| - at compressor output of 0.7 m³/min (2 x compressor V-Meko 400) | max. 10 l/min |
| - at compressor output of 1.5 m³/min | max. 13 l/min |
| Air consumption | 0.5 m³/min |
| Mixing ratio | 1 : 1 |
| Air pressure | max. 8 bar |
| Weight | 106 kg |
| L x W x H | 112 x 55 x 76 cm |
| Rinsing pump | |
| Working pressure - infinitely variable | 7 - 220 bar |
| Delivery rate | 5 l/min |
| Transmission ratio | 1 : 28 |
| Supply voltage (adjustable ex works) | 110 V/230 V |
| Electricity consumption | 350 W |
| Storage type | digitally on tablet |
| Hard disk space | 64 GB |
| Data transfer | WLAN |
| Measuring range - volume | 0,1 - 32 l/min |
| Measuring range - pressure | 0 - 250 bar |
| Measurement accuracy | ± 2 % |
| Weight - control cabinet | 11,2 kg |
| Weight - tablet | 2,7 kg |
| L x W x H - control cabinet | 21.5 x 30 x 30 cm |
| L x W x H - tablet | 10 x 27 x 25 cm |
WHAT IS INCLUDED
moving device, 1.2 m suction system Ø 20 mm with suction basket Ø 100 mm: component A and B: black, 2 x manometer 0 - 250 bar, rinsing pump S25, 1.2 m suction system Ø 13 mm with suction basket Ø 40 mm: black, material hose connection: component A: external thread M16x1,5; component B: external thread M14x1,5; rinsing connection: external thread M12x1,5; return hoses Ø 8 mm: transparent, air connection: air plug NW 7.2, DESOI w.i.l.m.a.: control cabinet with integrated control, 10 m supply cable, on/off switch, control lamp, 2 x flow sensor, pressure sensor, impact resistant and waterproof CATERPILLAR (up to 1 m): T20 Tablet with Windows 10, incl. instruction manual Professional instruction on the site by an experienced application technician and subsequent application support (approx. 2 hours). Arrival and departure will be charged on a time and material basis.
Product for professional use only.
